£57.75 (excl. VAT)
Internal Banding Section
The 100mm Box Section is an integral part of the 100mm banded system, designed to create a framed appearance when used in conjunction with our bars. This aluminium section for glass partitions is bonded internally to the glass, providing both structural support and a sleek, banded look.
Material: Aluminium 6063 T6 for durability and strength.
Dimensions: 59mm wide by 25mm thick.
Bonded internally to the glass, the 100mm aluminium box section works seamlessly with the 100mm banded system to achieve a fully framed screen.
This aluminium profile for double-glazed partitions is ideal for creating a modern, banded aesthetic, ensuring a professional and visually appealing finish.
Available in RAL 9005, 9010, 9006, 7016. For bespoke colours, please get in touch (POA).
The 100mm Box Section is a high-performance aluminium section for glass partition systems, designed to deliver structural strength and a refined, framed aesthetic. Part of the advanced 100mm aluminium frame system, this component is bonded internally to the glass and works seamlessly with horizontal and vertical bars to create a continuous banded visual across double-glazed screens.
Material: Aluminium 6063 T6 – high strength and corrosion resistance.
Dimensions: 59mm width x 25mm thickness.
Application: Internally bonded to 10mm/10.8mm or 12mm/12.8mm glass.
This aluminium profile is engineered to be used inside the glass panels, enhancing rigidity while contributing to the architectural design language of modern workspaces. It is the ideal solution for designers seeking a banded aluminium frame system without compromising glass clarity or installation efficiency.
Designed for optimal integration with other aluminium profiles in the 100mm system, the internal aluminium box section is compatible with leading bonding tapes and adhesives including Tesa 62510, Tesa 62505, and Scapa 3259. This ensures a reliable, long-lasting bond between glass and aluminium frames, critical for safety and performance.
The section fits effortlessly alongside components such as 100-1P, 100-2P, and 25-bar, forming a complete aluminium frame system for glass partitions that supports both function and form.
By using this aluminium channel for 10mm glass or aluminium channel for 12mm glass, designers can create a clean, professional finish across full-height partitions and banded glazed screens. It contributes to the overall rigidity of the system while maintaining the minimal, industrial look that defines high-end interiors.
Combined with Q-Lon acoustic seals in associated channels, this aluminium u channel for 10mm glass enhances both sound insulation and visual impact.
Standard RAL finishes include RAL 9005, 9010, 9006, and 7016. For customised colour finishes on your aluminium frames, bespoke powder coating is available upon request (POA), allowing full integration into any architectural design scheme.
We invite you to view our interactive, online PDF brochure, where you can browse through our entire collection of systems.
GET YOUR CATALOGUE
We are experts in manufacturing of aluminum products for glazed partitions, harnessing a wealth of experience. Our commitment to excellence ensures that we consistently meet our clients’ high expectations, delivering superior quality within the agreed timeframe and budget.
Alexander Hughes –
As a contractor specializing in industrial-style fit-outs, I find this 100mm internal banding section exceptional. The 6063 T6 aluminium is rigid and the RAL 9005 finish is flawless. We paired it with Scapa 3259 tape for the internal bond, and the framed screen look was perfect.
Harper-James –
been using the 100mm box section for a few office projects now. it is solid and fits the internal glass surface really well. we usually get the tesa 62510 tape to go with it for a permanent bond. the black ral 9005 looks brilliant when it is all finished. really good quality profile.
Theo Bennett –
Ordering the full kit including the 100-2P and the 25-Bar made the install go very smoothly. The box section arrived in perfect condition. It is much easier to achieve a consistent look across the whole office when the profiles are designed to work together.
Bristol.Boi.99 –
swapped to the 100mm banded system for our latest office job. the box section and tesa 62510 tape made it so much easier to get a professional result. the client loved the finish.
Eleanor Gray –
A very dependable solution for creating banded glass screens. This aluminium profile is durable and easy to install, providing a high-end finish for commercial interiors.
