Double-Glazed Door Frame
The 100mm Door Frame is a robust aluminium door frame profile designed for double-glazed systems, accommodating doors up to 44mm thick or 54mm rebated doors. It is suitable for frameless glass, framed glass, and timber doors, offering versatility for a wide range of applications. Can be used with a floor spring.
Material: Aluminium 6063 T6 for strength and durability.
The 100mm aluminium channel for glass doors features pre-drilled and countersunk holes at the head, internal locating mitre brackets, and an aluminium fixing plate for the bottom of the door legs. A pre-inserted Q-Lon acoustic seal enhances sound insulation, while a clip-in section at the top allows for easy ceiling installation.
A bespoke milling service for hinges and strike plates is available as per customer specification.
Compatible with all other components in the 100mm system, this aluminium door frame for double glazing ensures a precise fit and reliable performance in any installation.
All 100mm aluminium door frames are cut to a maximum length of 3000mm.
Available in RAL 9005, 9010, 9006, 7016. For bespoke colours, please get in touch (POA).
The 100mm Double-Glazed Door Frame is a precision-engineered aluminium door frame profile, designed to deliver strength, acoustic performance, and design flexibility across a wide range of commercial and residential installations. Ideal for use with frameless glass, framed glass, or timber doors, this profile supports both 44mm thick and 54mm rebated doors for versatile application.
Material: Manufactured from durable Aluminium 6063 T6 for long-term structural integrity.
Max Door Compatibility: Accepts 44mm standard or 54mm rebated doors.
Maximum Length: Supplied in standard 3000mm lengths for a tailored, precise fit.
The 100mm aluminium channel for glass door includes pre-drilled and countersunk fixing points, internal locating mitre brackets, and an aluminium fixing plate to secure door legs effectively. A clip-in top section simplifies installation at ceiling level, streamlining the setup process without compromising on aesthetics.
This aluminium door frame is fitted with a pre-inserted Q-Lon acoustic seal, ensuring excellent sound insulation, a key requirement in high-traffic environments like offices, meeting rooms, and public buildings.
To meet specific design and functional requirements, a bespoke milling service is available for hinge and strike plate cut-outs—customised according to your project specifications.
Fully compatible with all major components in the 100mm double-glazing system—including 100-deflection, 100-deep, 100-1P, and 100-2P—this aluminium door frame integrates seamlessly within any 100mm glass partition setup. Its design enables consistent transitions between walls, doors, and ceilings, ensuring a clean and cohesive installation.
Available in standard RAL finishes: RAL 9005, 9010, 9006, and 7016, this aluminium door frame profile supports a contemporary architectural finish. Bespoke colour options are also available on request (POA) to suit your design intent.
