£26.95 (excl. VAT)
Slimline Aluminium Profile: a sleek, single-glazed solution designed for use as a head and wall channel. Measuring 25mm in both width and height, with a length of 3000mm, this 25mm aluminium U channel is engineered for precision and durability.
It features a pre-inserted Q-Lon acoustic seal, accommodating glass thicknesses of 10mm/10.8mm or 12mm/12.8mm, ensuring excellent sound insulation. Crafted from high-grade Aluminium 6063 T6, the 25mm U channel delivers outstanding strength and durability, making it an ideal choice for modern architecture and glass partition systems.
This 25mm aluminium U section is compatible with all components in the 25mm aluminium profile system, perfect for framing and securing glass panels. Whether used as a 10mm glass channel or a 12mm glass U channel, this aluminium section for glass partition systems guarantees a secure fit for your glazing needs.
Available in RAL 9005, 9010, 9006, 7016. For bespoke colours, please get in touch (POA).
Our 25mm aluminium U channel is a high-quality profile made from Aluminium 6063 T6 alloy, engineered specifically for modern glass partition and glazing systems. It offers exceptional strength and stability, ensuring secure mounting for glass thicknesses of 10mm, 10.8mm, 12mm, and 12.8mm.
This aluminium u channel features a pre-inserted Q-Lon acoustic seal, significantly enhancing sound insulation — a crucial factor for office and architectural applications. The profile is fully compatible with all components in the 25mm aluminium profile system, including 25-bar, 25-DF, 25-deflection, 25-deep, and 25-2P, allowing flexible and comprehensive use across various constructions.
The aluminium u channel for glass comes in standard 3000mm lengths and is available in RAL colours 9005, 9010, 9006, and 7016, with bespoke colour options available on request (POA). It performs perfectly as a 10mm glass channel or 12mm glass U channel, ensuring a secure and sleek fit tailored to your project needs.
Exceptional strength due to high-grade Aluminium 6063 T6
Precision manufacturing with attention to detail
Fully compatible with the 25mm aluminium profile system
Integrated Q-Lon seal for superior acoustic insulation
Available in standard and custom RAL colours
In summary, our 25mm aluminium U channel is a reliable, professional solution for securing glass in partition systems, meeting the demands of even the most advanced architectural and interior design projects.
We invite you to view our interactive, online PDF brochure, where you can browse through our entire collection of systems.
GET YOUR CATALOGUE
We are experts in manufacturing of aluminum products for glazed partitions, harnessing a wealth of experience. Our commitment to excellence ensures that we consistently meet our clients’ high expectations, delivering superior quality within the agreed timeframe and budget.
Isabella Anderson –
we’ve installed this system in a few retail units and showrooms. the 25mm u channel is easy to work with, glass sits solid, and the seal already in the profile saves time. what matters to us is that it’s part of a full system – corners, doors, joints all from one supplier. no mixing brands on site. does the job well.
Matthew Baker –
APS offers a complete partition system rather than individual profiles that need adapting on site. The 25mm aluminium U channel works perfectly with both 10mm and 12mm glass, and integrates smoothly with other components like 25-2P and 25-bar. Installation is efficient, which is important for tight programmes. Standard RAL options cover most project needs. Technically sound and well thought out.
Oliver Smith –
We’ve used the APS 25mm system on several office fit-outs, including meeting rooms and open-plan partitions. The Slimline 25mm U channel is only one component, but it reflects the quality of the whole system very well. Tolerances are consistent, finish is clean, and the integrated Q-Lon seal noticeably improves acoustic performance. Combined with 25-DF door frames and 25-deflection profiles without any alignment issues. Reliable system for repeat commercial work.
