A versatile two-part single-glazed aluminium profile, designed for use as a base and wall channel. With dimensions of 25mm width by 25mm height, and a total length of 3000mm, this 25mm U channel system provides a perfect solution for glass partition installations.
This profile is built from two components: the 25mm chair and 25mm bead for added flexibility and ease of glass installation. The 25mm aluminium U section ensures a secure fit for 10mm/10.8mm or 12mm/12.8mm glass, delivering excellent performance in terms of durability and stability.
It comes with a pre-fitted Q-Lon acoustic seal, providing superior noise reduction and enhancing sound insulation between the glass panels. Constructed from robust Aluminium 6063 T6, the 25-2P offers exceptional strength and longevity for both residential and commercial applications.
Compatible with all components of the 25mm aluminium frame system, this versatile aluminium U channel is ideal for contemporary design applications requiring a sleek, functional, and strong frame for glass partitions.
Available in RAL 9005, 9010, 9006, 7016. For bespoke colours, please get in touch (POA).
The 25mm aluminium U channel two-part system offers a versatile and robust solution designed for use as both base and wall channels in single-glazed glass partitions. Measuring 25mm in width and height, with a length of 3000mm, this aluminium u section ensures a secure fit for glass thicknesses of 10mm/10.8mm and 12mm/12.8mm, meeting demanding architectural standards.
Comprised of two components — the 25mm chair and 25mm bead — this aluminium u channel for glass provides enhanced flexibility and simplifies glass installation. Equipped with a pre-fitted Q-Lon acoustic seal, the profile delivers superior noise reduction and sound insulation, crucial for both commercial and residential environments.
Constructed from premium Aluminium 6063 T6, this 25mm u channel aluminium combines durability with strength, ensuring long-lasting performance. It is fully compatible with the wider 25mm aluminium profile system, including 25-bar, 25-DF, 25-deflection, 25-deep, and 25-1P components, allowing seamless integration in modern glass partition frameworks.
The 25-2P aluminium U channel is available in standard RAL finishes — 9005 (Black), 9010 (White), 9006 (Silver), and 7016 (Anthracite). Bespoke colour options can also be provided on request (POA), offering tailored aesthetic solutions to complement any interior design.
Two-part system (chair and bead) for easy glass installation
Compatible with 10mm and 12mm glass thicknesses
Pre-inserted Q-Lon acoustic seal for enhanced sound insulation
Manufactured from high-grade Aluminium 6063 T6 for strength and longevity
Full compatibility with 25mm aluminium profile system components
This aluminium u profile is an excellent choice for architects, designers, and installers seeking a reliable, professional-grade aluminium channel for glass partitions that combines sleek design with robust functionality.
