Single-glazed, one-part aluminium profile designed for use as a head channel, offering a deflection range of +/- 20mm. Measuring 25mm in width and 50mm in height, this 25mm aluminium U channel ensures both flexibility and durability in a range of installations, especially for glass partition systems.
Equipped with a pre-inserted Q-Lon acoustic seal, it accommodates glass thicknesses of 10mm/10.8mm or 12mm/12.8mm, providing excellent sound insulation. As with all components in the 25mm aluminium frame system, the 25-Deep section is 3000mm in length and fully compatible with the complete 25mm profile range, ensuring seamless integration with other 25mm U shaped aluminium channels and sections.
This aluminium U profile is ideal for creating robust and sleek single-glazed installations and can be used in various architectural applications, such as glass partitions and modern door systems.
Available in RAL 9005, 9010, 9006, 7016. For bespoke colours, please get in touch (POA).
The 25mm aluminium U channel 25-Deep is a single-part aluminium profile designed specifically as a head channel for single-glazed installations. Measuring 25mm in width and 50mm in height, it provides a unique deflection range of ±20mm, offering exceptional flexibility while maintaining structural durability in glass partition systems.
Engineered to accommodate glass thicknesses of 10mm, 10.8mm, 12mm, and 12.8mm, this aluminium u profile features a pre-inserted Q-Lon acoustic seal to ensure superior sound insulation. This makes the aluminium channel for glass ideal for modern architectural applications requiring both noise control and visual transparency.
The 25-Deep aluminium U channel is supplied in 3000mm lengths and is fully compatible with the comprehensive 25mm aluminium frame system, including products such as 25-bar, 25-DF, 25-2P, and 25-1P. This ensures seamless integration and easy installation across diverse projects involving u channel aluminum and u shaped aluminum channels.
Designed for use in contemporary glass partitions and modern door systems, the 25mm u channel aluminium offers both a sleek aesthetic and reliable performance. Available in standard RAL finishes — 9005 (Black), 9010 (White), 9006 (Silver), and 7016 (Anthracite) — with bespoke colours available on request (POA), this profile suits a wide range of design requirements.
Single-part head channel profile with ±20mm deflection capacity
Compatible with 10mm and 12mm glass thicknesses
Integrated Q-Lon seal for acoustic insulation
Manufactured from durable Aluminium 6063 T6
Full compatibility within the 25mm aluminium profile system
In summary, the 25mm aluminium U channel 25-Deep is an optimal choice for architects and installers seeking a flexible, durable, and sound-insulated aluminium section for glass partition systems that meet the highest standards of performance and design.
