Double-Glazed Head Deflection Set
The 100mm Deflection Set is designed for double-glazed systems, offering a deflection range of +/- 25mm to accommodate structural movement while maintaining a secure fit. This set includes both male and female aluminium sections for glass partitions that work together seamlessly.
Material: Aluminium 6063 T6 for durability and strength.
Dimensions:
Female section: 107.5mm wide x 68mm high.
Male section: 100mm wide x 63mm high.
Overall dimensions: 107.5mm / 100mm in width and 93mm in height.
The 100mm aluminium channel for 10mm glass and 100mm aluminium channel for 12mm glass features a pre-inserted Q-Lon acoustic seal in the male section, accommodating glass thicknesses of 10mm/10.8mm or 12mm/12.8mm. The female section includes a pre-inserted brush to prevent scratching between the components.
Fully compatible with all components in the 100mm system, this double-glazed aluminium frame set ensures superior acoustic insulation and structural flexibility for both commercial and residential double-glazed installations. Each component measures 3000mm in length.
Available in RAL 9005, 9010, 9006, 7016. For bespoke colours, please get in touch (POA).
The 100mm Deflection Set is expertly designed for double-glazed systems, providing a deflection range of ±25mm to effectively accommodate structural movement without compromising the integrity of the glass partition. This set includes both male and female aluminium sections that work together to ensure a secure and seamless installation.
Material: High-grade Aluminium 6063 T6 for exceptional strength and long-term durability.
Female section dimensions: 107.5mm wide x 68mm high
Male section dimensions: 100mm wide x 63mm high
Overall height: 93mm, supporting robust double glazing aluminium frames.
The male section is equipped with a pre-inserted Q-Lon acoustic seal, compatible with 10mm/10.8mm and 12mm/12.8mm glass thicknesses, enhancing sound insulation. Meanwhile, the female section includes a pre-inserted brush seal that prevents scratching and ensures smooth component interaction.
Fully compatible with all 100mm system components such as 100-box, 100-DF, 100-deflection, 100-deep, and 100-1P, this head deflection set offers unmatched compatibility for double glazing frames. Designed for use as an aluminium channel for 10mm glass, aluminium channel for 12mm glass, and an aluminium channel for glass door applications, it provides both structural flexibility and superior acoustic performance.
This aluminium section for glass partition is perfect for both commercial and residential projects requiring reliable deflection accommodation. The set’s length of 3000mm allows for easy customization and precise fitting within larger double glazing aluminium frames, including aluminium u channel for 10mm glass and aluminium u channel for 12mm glass configurations.
Available finishes: RAL 9005, 9010, 9006, 7016. Custom colours available upon request (POA).
